Authentik Overview - Architecture, Features, and Comparison with Keycloak

Stilicho2011Updated 5 min read26 views

Also available in: RU

Authentik Overview - Architecture, Features, and Comparison with Keycloak
Part 3 of 3 in the series IAM-решения
  1. Authentik vs Authelia vs Keycloak vs Zitadel - SSO Compared
  2. TOTP vs WebAuthn vs Passwordless - What's the Difference and Which One to Choose
  3. Authentik Overview - Architecture, Features, and Comparison with Keycloak
Contents

Why you need Authentik at all (and what IAM / IdP means in a homelab / production)

Why solutions like Authentik / IAM / IdP are needed

In basic setups, each service (application, web interface, API) often implements its own form of login - its own users, password storage, session mechanism, and so on. This creates:

  • Duplicated authentication/authorization logic
  • Different passwords across different systems
  • A larger security-error surface
  • Difficulties with centralized user management, MFA, and auditing
  • Problems with a unified session (SSO) across systems

Solutions like IAM / IdP (Identity Provider) allow you to centralize authentication and authorization: services "delegate" the login process to the IdP solution, and the IdP issues a token/session/assertions that the services trust.

Benefits in a production environment

  • Centralized security policy (MFA, IP restrictions, time-limited access)
  • Unified auditing and logging
  • Integration with LDAP, AD, and third-party OAuth providers
  • Scalability: adding new services without duplicating authentication

In a homelab / self-hosted environment

  • Control over your own data and passwords
  • The ability to experiment with policies and customization
  • Single sign-on for multiple home services (Nextcloud, Home Assistant, etc.)
  • Levelling up your infrastructure to a production-grade level

Bottom line: Authentik is one of the solutions that combines convenience, flexibility, and an open-source approach, making it suitable for both home labs and production.


What Authentik is - a brief overview

Authentik is an open-source / open-core Identity Provider (IdP) and Single Sign-On (SSO) system, built with an emphasis on flexibility and extensibility.

Key capabilities

  • Support for standards: OAuth2 / OIDC, SAML2, LDAP, SCIM, RADIUS
  • A Flows / Stages mechanism for building authentication scenarios
  • A convenient UI for admins and users
  • Self-service (registration, password recovery, MFA)
  • Conditional access policies
  • API, Terraform, Blueprints - configuration as code
  • Scaling from Docker to Kubernetes / Helm
  • Support for external identity providers

An IdP is a critically important security element. Authentik needs to be regularly updated and monitored. In 2024, vulnerabilities related to certificate management were reported, but they were promptly fixed.


Core concepts

Concept Description
Flows / Stages The logic of the authentication sequence (password, MFA, IP check, etc.).
Applications / Providers Configuration of applications and login providers (OIDC, SAML, etc.).
Policy / Conditions Access control based on attributes (group, IP, time of day).
SCIM / LDAP / Federation Syncing users from external systems.
Self-Service / Enrollment Interface for users (password change, MFA, etc.).
Consent / Attribute Mapping Managing the attributes passed to applications.
API / Automation Full automation of configuration via API, Terraform, Blueprints.

Advantages and limitations

Advantages

  • High flexibility and customizability (flows, policies).
  • Support for a wide range of protocols (OIDC, SAML, LDAP, RADIUS).
  • Suits small/medium environments and Kubernetes clusters.
  • Simpler interface compared to Keycloak.
  • API and Terraform for automation.
  • Open source - control over your data and code.

Limitations

  • A smaller community than Keycloak's.
  • May require optimization under heavy load.
  • Requires regular updates and auditing.
  • Some features are available only in the enterprise version.
  • Configuring flows requires experience.

Comparing Authentik with competitors

Characteristic Authentik Keycloak Authelia Auth0 / Okta (SaaS)
Solution type Self-host / open core Self-host / enterprise Self-host / gateway SaaS / managed
Supported protocols OAuth2 / OIDC, SAML2, LDAP, SCIM, RADIUS OAuth2 / OIDC, SAML2, Kerberos, LDAP / AD SSO / 2FA, limited protocols OAuth2 / OIDC, SAML, social login
Customization Very flexible (flows, policies) High (plugins) Simple Minimal
Integrations LDAP, SCIM, external OAuth LDAP / AD, federation LDAP Many ready-made ones
Installation Docker, Helm, UI Java stack (heavy) Lightweight No installation
Scalability Medium loads, clustering Enterprise Small scenarios Unlimited
Community Young, fast-growing Mature Niche Huge
Security Requires updates Mature Simplified High (SLA)
Cost Free / enterprise support Free / Red Hat support Free Subscription
Best use case Homelab, SMB, customization Enterprise Simple SSO / 2FA No admin overhead

Authentik is often called the "golden middle ground" between heavy IAM solutions and simple proxy systems like Authelia.

A more detailed comparison of Authentik, Authelia, Keycloak, and ZITADEL against each other (by features, installation complexity, resource usage) is in a separate comparison article.


Installation and architectural recommendations

Installation approaches

  • Docker Compose - ideal for a homelab and testing
  • Kubernetes / Helm - for production
  • Cloud AMI / Marketplace - ready-made images (AWS, etc.)

Architecture and tips

  • Separate the services: PostgreSQL, Redis, Authentik web/worker.
  • Use external DB and Redis.
  • Set up backups.
  • Ensure TLS/HTTPS for the interfaces.
  • Set up monitoring and updates.
  • Use clustering and replication if needed.

Minimal installation example (Docker Compose) version 2025.10.1

Note

Update note. At the time of publication, the current version was 2025.10.1, but Authentik releases often - as of August 2026, the current branch is 2026.5.x. Don't blindly copy the version tag: before installing, check the releases page on GitHub and substitute the current AUTHENTIK_TAG. The overall structure of the docker-compose file hasn't fundamentally changed since then.

yaml
---
services:
postgresql:
image: docker.io/library/postgres:16-alpine
container_name: authentik_postgres
restart: unless-stopped
healthcheck:
interval: 30s
retries: 5
start_period: 20s
test:
- CMD-SHELL
- pg_isready -d $${POSTGRES_DB} -U $${POSTGRES_USER}
timeout: 5s
volumes:
- database:/var/lib/postgresql/data
environment:
POSTGRES_PASSWORD: ${PG_PASS:?database password required}
POSTGRES_USER: ${PG_USER:-authentik}
POSTGRES_DB: ${PG_DB:-authentik}
env_file:
- .env
networks:
authentik:
#
server:
command: server
depends_on:
postgresql:
condition: service_healthy
env_file:
- .env
image: ${AUTHENTIK_IMAGE:-ghcr.io/goauthentik/server}:${AUTHENTIK_TAG:-2025.10.1}
container_name: authentik_server
restart: unless-stopped
environment:
AUTHENTIK_REDIS__HOST: redis
AUTHENTIK_POSTGRESQL__HOST: postgresql
AUTHENTIK_POSTGRESQL__USER: ${PG_USER:-authentik}
AUTHENTIK_POSTGRESQL__NAME: ${PG_DB:-authentik}
AUTHENTIK_POSTGRESQL__PASSWORD: ${PG_PASS}
TZ: Europe/Moscow
volumes:
- ./media:/media
- ./custom-templates:/templates
networks:
authentik:
proxy:
labels:
- "traefik.enable=true"
- "traefik.http.routers.authentik.entrypoints=web"
- "traefik.http.routers.authentik.rule=Host(`authentik.domain.ru`)"
- "traefik.http.middlewares.authentik-https-redirect.redirectscheme.scheme=https"
- "traefik.http.routers.authentik.middlewares=authentik-https-redirect"
- "traefik.http.routers.authentik-secure.entrypoints=websecure"
## Individual Application forwardAuth regex (catch any subdomain using individual application forwardAuth)
- "traefik.http.routers.authentik-secure.rule=Host(`authentik.domain.ru`) || HostRegexp(`{subdomain:[a-z0-9]+}.domain.ru`) && PathPrefix(`/outpost.goauthentik.io/`)"
- "traefik.http.routers.authentik-secure.tls=true"
- "traefik.http.routers.authentik-secure.service=authentik"
- "traefik.http.services.authentik.loadbalancer.server.port=9000"
- "traefik.docker.network=proxy"
#
worker:
image: ${AUTHENTIK_IMAGE:-ghcr.io/goauthentik/server}:${AUTHENTIK_TAG:-2025.10.1}
restart: unless-stopped
command: worker
container_name: authentik_worker
environment:
AUTHENTIK_REDIS__HOST: redis
AUTHENTIK_POSTGRESQL__HOST: postgresql
AUTHENTIK_POSTGRESQL__USER: ${PG_USER:-authentik}
AUTHENTIK_POSTGRESQL__NAME: ${PG_DB:-authentik}
AUTHENTIK_POSTGRESQL__PASSWORD: ${PG_PASS}
TZ: Europe/Moscow
# `user: root` and the docker socket volume are optional.
# See more for the docker socket integration here:
# https://goauthentik.io/docs/outposts/integrations/docker
# Removing `user: root` also prevents the worker from fixing the permissions
# on the mounted folders, so when removing this make sure the folders have the correct UID/GID
# (1000:1000 by default)
#user: root
volumes:
- /var/run/docker.sock:/var/run/docker.sock
- ./media:/media
- ./certs:/certs
- ./custom-templates:/templates
env_file:
- .env
depends_on:
postgresql:
condition: service_healthy
networks:
proxy:
authentik:
#
volumes:
database:
driver: local
#
networks:
proxy:
external: true
authentik:
external: true
yaml
PG_PASS=pass
AUTHENTIK_SECRET_KEY=secret
# SMTP Host Emails are sent to
AUTHENTIK_ERROR_REPORTING__ENABLED=true
AUTHENTIK_EMAIL__HOST=smtp.gmail.com
AUTHENTIK_EMAIL__PORT=465
# Optionally authenticate (don't add quotation marks to your password)
AUTHENTIK_EMAIL__USERNAME=mail@gmail.com
AUTHENTIK_EMAIL__PASSWORD=password
# Use StartTLS
AUTHENTIK_EMAIL__USE_TLS=false
# Use SSL
AUTHENTIK_EMAIL__USE_SSL=true
AUTHENTIK_EMAIL__TIMEOUT=10
# Email address authentik will send from, should have a correct @domain
AUTHENTIK_EMAIL__FROM=mail@gmail.com
AUTHENTIK_ERROR_REPORTING__ENABLED=true
