Today we continue polishing our NAS. This time we'll tackle one of ZFS's coolest features - snapshots. And to avoid doing everything by hand, we'll immediately automate the process using the Sanoid utility.
Why do we even need snapshots?
ZFS is a very powerful and incredibly reliable filesystem. Of course, it's not without its drawbacks, but its advantages far outweigh them.
One of ZFS's main features is snapshots. Essentially, this is a snapshot of the filesystem's state at a particular point in time. If something goes wrong - you accidentally deleted files, botched a system update, or got hit by ransomware - you can simply roll back to a previous state, as if nothing had happened.
Of course, this doesn't come completely for free. Snapshots take up disk space, but only for changed data. As long as files don't change, a snapshot weighs almost nothing. So you only pay for the changes, not for a full copy of the data.
In TrueNAS, snapshot management is exposed through a convenient WebUI. Fedora Server doesn't have that convenience - Cockpit doesn't yet fully support working with ZFS.
But that's not a big deal, we'll manage here too.
Working with snapshots manually
First, let's take a look at how snapshots work manually.
# Create a snapshot
sudo zfs snapshot data/media@before-upgrade
# Roll back to a snapshot
sudo zfs rollback data/media@before-upgrade
# Check pool integrity (recommended roughly once a month)
sudo zpool scrub data
For local access, you can enable display of the .zfs directory:
sudo zfs set snapdir=visible data/media
However, Samba doesn't expose this internal directory to SMB clients. If you want to use snapshots directly from Windows Explorer through the "Previous Versions" menu, you'll need to configure the shadow_copy2 module. This is exactly how this feature is implemented in TrueNAS.
After that, a hidden .zfs folder will appear in the directory, inside which you can browse the contents of all snapshots. Sometimes this turns out to be very handy if you need to quickly grab an accidentally deleted file without a full filesystem rollback.
However, even though manual labor ennobles a person, like any other labor, our memory is an unreliable thing. Personally, I don't want to use AI agents, and giving them access to your data is a pretty bold idea. Bold, but dumb.
So let's automate this whole process using the widely-known-in-narrow-circles utility set Sanoid.
Sanoid can automatically create snapshots on a schedule, remove outdated ones, and maintain a defined retention policy without any user involvement.
Installing Sanoid
Step 1. Install the required dependencies
First, let's install Git and all the libraries needed for Sanoid to work.
sudo dnf install -y \
git \
perl-Config-IniFiles \
perl-Data-Dumper \
perl-Capture-Tiny \
perl-Getopt-Long \
lzop \
mbuffer \
mhash \
pv
On Fedora, all the necessary Perl modules are already in the official repositories, so there's no need to enable EPEL or install anything via CPAN.
Step 2. Download Sanoid
Move to a temporary directory and clone the project's official repository.
Of course, you could stay on the master branch, but personally I prefer to use stable releases. A home NAS isn't the place where you want to unexpectedly hit a bug after some random update.
There's nothing complicated here. This service simply runs Sanoid, which creates snapshots according to the configuration we're about to write.
Pay attention to this line:
ConditionFileNotEmpty=/etc/sanoid/sanoid.conf
It prevents the service from starting until we've created the configuration file. A very useful little detail that saves us from unnecessary errors during initial setup.
This service handles cleanup: it removes snapshots whose retention period has already expired according to our policy.
This way, we won't have to think at all about when to clean up old snapshots - Sanoid handles everything itself.
Creating a timer
All that's left is to teach systemd to run Sanoid on a schedule.
Let's create a timer:
sudo nano /etc/systemd/system/sanoid.timer
And insert:
[Unit]
Description=Run Sanoid every 15 minutes
Requires=sanoid.service
[Timer]
OnCalendar=*:0/15
Persistent=true
[Install]
WantedBy=timers.target
In my case, Sanoid runs every 15 minutes.
For a home NAS, that's more than enough. If your data changes rarely, you can safely increase the interval, for example to once an hour.
Enabling the services
Now that all the services have been created, all that's left is to inform systemd about them and enable automatic startup.
First, let's reload the configuration:
sudo systemctl daemon-reload
Let's allow the snapshot cleanup service to run:
sudo systemctl enable sanoid-prune.service
And enable the timer:
sudo systemctl enable --now sanoid.timer
You can check that the timer started successfully with:
systemctl list-timers sanoid.timer
The expected result will look something like this:
NEXT LEFT LAST
Fri 2026-07-17 10:15:00 12 min Fri 2026-07-17 10:00:00
At this point, the installation is fully complete.
Verifying the installation
For your own peace of mind, you can confirm that Sanoid is indeed installed.
For example, check its version:
sanoid --version
Or open the built-in help:
sanoid --help
If the commands run without errors, everything went fine.
Configuring the snapshot schedule
At this point, there's one small caveat.
Sanoid is already installed.
The timer is already running.
Systemd is already trying to run Sanoid every 15 minutes.
But... it won't actually do anything yet.
That's because we haven't yet told it which datasets to maintain and how many snapshots to keep.
So let's open the main configuration file:
sudo nano /etc/sanoid/sanoid.conf
By default, Sanoid ships with a large number of ready-made templates. If you're curious to see all of the utility's capabilities, I recommend checking out the official example configuration:
But for a home NAS, that level of configuration complexity usually isn't needed.
Let's assume our pool is called data, and all user data lives in the data/media dataset.
Then the sanoid.conf file will look like this:
[data/media]
use_template = production
[template_production]
frequently = 0
hourly = 36
daily = 30
weekly = 4
monthly = 3
yearly = 0
autosnap = yes
autoprune = yes
Let's break down what these parameters mean.
With this configuration, Sanoid will automatically:
keep 36 hourly snapshots;
keep 30 daily snapshots;
keep 4 weekly snapshots;
keep 3 monthly snapshots;
not create "frequent" (frequently) or yearly (yearly) snapshots.
The parameter
autosnap = yes
enables automatic snapshot creation.
And the parameter
autoprune = yes
automatically removes old snapshots whose retention period has already ended.
Important. Replace data/media with the name of your own ZFS dataset. You can find it out with the command:
zfs list
If you need to protect the entire pool at once
If your pool has multiple datasets (media, documents, backups, nextcloud, and so on), it's much more convenient to use recursive processing.
In that case, it's enough to write:
[data]
use_template = production
recursive = yes
[template_production]
frequently = 0
hourly = 36
daily = 30
weekly = 4
monthly = 3
yearly = 0
autosnap = yes
autoprune = yes
Now Sanoid will automatically maintain all child datasets inside the data pool.
In my view, this is the most convenient option for a home NAS. You won't need to add new datasets to the configuration by hand every time - they'll automatically fall under the retention policy. This is especially handy if you experiment a lot and frequently create new datasets.
Verifying that everything works
Let's take another look at what we've already done.
✅ Installed Sanoid.
✅ Created the snapshot creation service.
✅ Created the old-snapshot cleanup service.
✅ Configured the systemd timer.
✅ Defined the snapshot retention policy.
Now, every 15 minutes, systemd will try to run Sanoid.
You can view the list of all active timers with the command:
sudo systemctl list-timers
And here there's one important point.
As long as the /etc/sanoid/sanoid.conf file is empty, nothing will happen. That's exactly why we earlier added the line:
ConditionFileNotEmpty=/etc/sanoid/sanoid.conf
As soon as you save a configuration with at least one dataset, the next timer run will automatically start creating snapshots.
You don't need to do anything else. No need to restart the timer, reboot the server, or re-enable the services - systemd will pick up the new configuration on its own.
If you don't want to wait for the next 15 minutes, you can test it manually.
Create snapshots:
sudo sanoid --take-snapshots --verbose
Or run the service that's normally triggered by the timer:
sudo systemctl start sanoid.service
After that, you can confirm the snapshot actually appeared:
zfs list -t snapshot
If you see a new snapshot - congratulations, everything is working exactly as it should.
But what about backups?
Here it's very important to understand one thing.
Snapshots are not backups.
Yes, they protect very well against accidental file deletion, botched updates, or ransomware actions. But if the disk itself fails, or the controller dies, or the entire server burns down, all the snapshots will disappear along with it.
So snapshots are the first line of data defense, not a full-fledged backup.
Syncoid - the next step
Fortunately, the Sanoid developers thought of this too.
Sanoid comes bundled with another great utility - Syncoid. It can replicate ZFS datasets to another pool, another server, or even another geographic location over SSH.
The simplest example looks like this:
sudo syncoid -r data backup
where:
data - the pool or dataset we're replicating;
backup - the pool or dataset the data will be sent to.
At first glance, the command looks very simple, but under the hood Syncoid does quite serious work. The utility figures out on its own which data has changed since the last sync, transfers only the difference between snapshots, and automatically resumes the transfer if the connection unexpectedly drops.
That's exactly why the Sanoid + Syncoid combo is considered one of the best solutions for organizing backups on top of ZFS.
Conclusion
With that, setting up automatic snapshots can be considered complete.
Your NAS can now, on its own:
create snapshots on a schedule;
automatically remove outdated snapshots;
maintain a defined retention policy without any user involvement.
In the next article, we'll take a detailed look at Syncoid and set up full-fledged replication of data between two ZFS pools. After that, our NAS will be able to survive not just accidental file deletion, but the failure of an entire server.
